Description
Standard: BS 1377:2
Liquid Limit : Cone Method
Newly up graded design come with fully automated system for easy operation and high accuracy result. Used to determine the moisture content of clay soil pass from plastic to a liquid status.
FEATURES:-
*Solid & compact design
*With find height adjustable system
*Selectable penetration timer
*Immediate print result (Optional)
Technical Specifications:
| Model Number | 5003 X / 005 |
| Accuracy | 0.01 mm |
| Penetration Range | Up to 50 mm |
| Display Unit | Digimatic Display |
| Product Dimension (mm) | 310 (L) x 210 (W) x 500 (H) |
| Packing Dimension (mm) | 340 (L) x 240 (W) x 470 (H) |
| Approx. Product Weight | 5.5 kg |
| Approx. Packing Weight | 6.5 kg |
| Power | 220 V, 50 / 60 Hz, 1 ph |
