Standards : BS EN ISO 148, ASTM E23
Resilience Test
This machine is mainly used to determine the anti-impact capability of ferrous metal with high toughness especially for steel and iron and their alloy, under dynamic load. Be applicable for continuing testing in different kinds of laboratories and other metallurgy industrial manufactories.
Technical Specifications :
| Model Number | 6002 X / 002 |
| Alternate Code | HD-R802-2 |
| Testing Material | Steel |
| Impact Energy | 150J (±1J) / 300J(±2J) |
| The Distance Between the Pendulum Shaft and Impact Tester |
750 mm |
| Impact Speed | 5.2 m/s |
| Pre-rising Angle of the Pendulum | 150° |
| Specimen Bearer Span | 40 mm |
| Round Angle of the Jaw | R1 ~ 1.5 mm |
| Impact Cutter Radius | R2 ~ 2.5 mm |
| Standard Full Size Specimen | 10 x 10 x 55 mm with V notch in the middle |
| Dimension (LxWxH) | 2124 x 600 x 1340 mm |
| Weight | 550 kg |
| Power | 380 ~ 415 V, 3 Ph, 50/60 Hz |
