Sample Preparation by Roller Compaction
Using the roller compactor, slab can be compacted to be compacted to a target density using load. To prepare wheel tracking specimen and to provide slave / to be cut for bending fatigue test. The units is pneumatically powered and is fully enclosed by a safety cutout switches for complete operator safety.
The apparatus comprises :-
*Steel frame roller compactor with roller segment reciprocating mould support table, pneumatic actuators for reciprocating table and applying compaction force.
*PLC controller for compacting start, emergency stop, automatic selection and number of roller passes.
*Different level of vertical for can be selected up to approximately 12 kN.
Technical Specifications:
| Model Number | NL 2003 X / 002A |
| Rolling Wheel Radius | 500 mm, Width 300 mm |
| Roller Car Moving Speed | 6 times / min (Forward & Reverse) |
| Roller Car Moving Distance | 300 mm |
| Roller Car Cycle Setting | 1 – 999 Cycle |
| Rolling Wheel Line Pressure | 9 kN |
| Rolling Wheel Temperature Range | RT – 200°C |
| Dimension (mm) | 1200 (L) x 600 (W) x 1790 (H) |
| Approx. Weight | 400 kg |
| Power | 380 ~ 415 V, 3 KW, 3 Ph, 50/60 Hz |
