Standard: ASTM E18, ISO 6508-2
Hardness Test
The Rockwell Hardness Tester designed to determines the hardness by measuring the depth of an indentor under specified load compared to the penetration made by a preliminary test force.
Technical Specifications :
| Model Number | NL 6004 X / 002 |
| Preliminary Test Force | 98.07 N (10kgf) |
| Horizontal Clearance (from centre) | 130 mm |
| Max. Height of the test piece | 170 mm |
| Total test force | 588 N (60 kgf) 980 N (100 kgf) 1471 kN (150 kgf) |
| Rockwell Scale | C = 0 ~100 B = 30 ~ 130 |
| Dwell Time | 5~60 sec |
| Type | Mechanical, analog |
| Resolution | 0.5 |
| Product Dimensions | 230 (L) x 470 (W) x 630 (H) mm |
| Approx. Weight | 75 kg |
